(1) Conductors
Number of conductors: 2, 3, 4 or 5. The conductors comply with the requirements given in IEC 60228 for class 5 conductors.
(2) Insulation
The insulation is polyvinyl chloride compound of type PVC/D applied around each conductor.
(3) Assembly of cores and fillers
Circular cord: The cores and the fillers are twisted together.
Flat cord: The cores are laid parallel.
For circular cords with two cores, the space is filled by separate fillers or by the sheath filling the interstices. Fillers do not adhere to the cores.
(4) Sheath
The sheath is polyvinyl chloride compound of type PVC/ST5. It fills the spaces between cores to form a filling but does not adhere to the cores. The assembly is surrounded by a separator where necessary, ensuring a practical circular cross-section for circular cords.
Maximum conductor temperature in normal use: 70°C
Compliance: The cable type 60227 IEC 53 complies with IEC 62440, providing safety guidance for electric cables with a rated voltage not exceeding 450/750 V.
| Number and nominal cross-sectional area of conductors (mm²) | Thickness of insulation (Specified value mm) | Thickness of sheath (Specified value mm) | Mean overall dimensions (mm) | Minimum insulation resistance at 70°C (MΩ · km) | |
|---|---|---|---|---|---|
| Lower limit | Upper limit | ||||
| 2 × 0.75 | 0.6 | 0.8 | 5.7 or 3.7 × 6.0 | 7.2 or 4.5 × 7.2 | 0.011 |
| 2 × 1 | 0.6 | 0.8 | 5.9 or 3.9 × 6.2 | 7.5 or 4.7 × 7.5 | 0.010 |
| 2 × 1.5 | 0.7 | 0.8 | 6.8 | 8.6 | 0.010 |
| 2 × 2.5 | 0.8 | 1.0 | 8.4 | 10.6 | 0.009 |
| 2 × 4 | 0.8 | 1.1 | 9.7 | 12.1 | 0.007 |
| 3 × 0.75 | 0.6 | 0.8 | 6.0 | 7.6 | 0.011 |
| 3 × 1 | 0.6 | 0.8 | 6.3 | 8.0 | 0.010 |
| 3 × 1.5 | 0.7 | 0.9 | 7.4 | 9.4 | 0.010 |
| 3 × 2.5 | 0.8 | 1.1 | 9.2 | 11.4 | 0.009 |
| 3 × 4 | 0.8 | 1.1 | 10.3 | 12.8 | 0.007 |
| 4 × 0.75 | 0.6 | 0.8 | 6.6 | 8.3 | 0.011 |
| 4 × 1 | 0.6 | 0.9 | 7.1 | 9.0 | 0.010 |
| 4 × 1.5 | 0.7 | 1.0 | 8.4 | 10.5 | 0.010 |
| 4 × 2.5 | 0.8 | 1.1 | 10.1 | 12.5 | 0.009 |
| 4 × 4 | 0.8 | 1.2 | 11.5 | 14.3 | 0.007 |
| 5 × 0.75 | 0.6 | 0.9 | 7.4 | 9.3 | 0.011 |
| 5 × 1 | 0.6 | 0.9 | 7.8 | 9.8 | 0.010 |
| 5 × 1.5 | 0.7 | 1.1 | 9.3 | 11.6 | 0.010 |
| 5 × 2.5 | 0.8 | 1.2 | 11.2 | 13.9 | 0.009 |
| 5 × 4 | 0.8 | 1.3 | 12.8 | 15.9 | 0.007 |
Utilization of high-quality raw materials and advanced manufacturing ensures products meet strict specifications. Quality is monitored across four stages: raw material, in-process, semi-finished, and finished product inspection with full traceability.
Ample inventory across all categories allows for immediate fulfillment of urgent demands. Flexible production management efficiently addresses diverse and time-sensitive requirements.
Sophisticated workflows for custom projects supported by dedicated expert teams in R&D, production, and after-sales to ensure professional solutions for specific needs.
The maximum conductor temperature for these cables in normal use is 70°C.
Both the insulation and the sheath are made from high-quality polyvinyl chloride (PVC) compounds, specifically type PVC/D for insulation and PVC/ST5 for the sheath.
Yes, the 60227 IEC 53 cable is available in both circular cord (cores twisted together) and flat cord (cores laid parallel) configurations.
This cable type can be manufactured with 2, 3, 4, or 5 conductors depending on the application requirement.
The conductors comply with the international standard IEC 60228 for Class 5 conductors, ensuring flexibility and reliable performance.
